HCVR-3 – Conventional Releasing Fire Alarm Control Panel Red
Description
The HCVR-3 is a 3 zone conventional releasing fire alarm control panel that is UL Listed and FM Approved
for releasing. The HCVR-3 can be configured to activate releasing by a single zone or combination of any two zones. The LCD display is used to show the countdown timer during activation of the releasing sequence. The HCVR-3 is fully programmable using simple menu options. The panel is a single board construction which provides an easy replacement solution. It is also compatible with a wide range of devices.
Standard Features
• UL 864 Listed and FM Approved
• Three detection zones
• Any single zone or any combination of zones can be configured to release
• Fully programmable using simple menu options
• Simple, single board construction
• Installer friendly
• Compatible with wide range of detection devices
• Configurable first stage NAC delays
• Configurable detection delays
• Built-in Manual Release switch and separate circuit
• Compatible with FirePro Xtinguish™
• Compatible with various releasing valves
• Configurable releasing delays up to 60 seconds in 5 second intervals
• Configurable releasing duration up to 5 minutes in 5 second intervals
• Releasing countdown timer displayed on the LCD
• Supports up to seven HCVR-SDU or HCVR-AB
• Built-in relays for Fire, Trouble, Stage 1, Stage 2, Extract and Local Fire
Resources and Downloads
| Conventional Releasing Fire Alarm Control Panel | Download PDF |
| HCVR-3 Manual Installation & Operation | Download PDF |
