SOC-24VN – Photoelectric Smoke Detector, Conventional
The SOC-24VN is a reliable, high quality Photoelectric Smoke Detector. It can be used in all areas where Photoelectric Smoke Detectors are required. The computer-designed smoke chamber makes the SOC-24VN well suited for detecting smoldering fires as well as fast-flaming fires.
NS-4 Series, NS-6 Series, HSC-4R or HSC-R Style bases may be used with the SOC-24VN.
NS-4 Series, NS-6 Series, HSC-4R or HSC-R Style bases may be used with the SOC-24VN.
STANDARD FEATURES
- Computer-designed non-directional smoke chamber
- 360° view of detector status LED
- Low profile, 2″ high (with base)
- 2 or 4 wire base compatibility, relay bases available
- Highly stable operation, RF/Transient protection
- Low standby current, 59µA at 24VDC
- One built-in power/sensitivity supervision/alarm LED
- Automatic Sensitivity window verification function meets outlined requirements in NFPA 72, Chapter 2 & 7, Inspection, Testing and Maintenance
- Without Magnetic Test Feature
Resources and Downloads
| Hochiki_HCV-2-4-8_02-2010 | Download PDF |
| Hochiki_HCV Series Conventional Panel Manual V1.03 | Download PDF |
