GRCBT-TIS – Copper-Bonded Ground Rod (TIS Series) Threaded Type
Copper-Bonded Ground Rod is made by molecularly bonding pure electrolytic copper onto a low carbon, high tensile steel core with exceeding 0.25 mm (250 micron) thick. The material made of 99.9% pure electrolytic copper with high tensile steel. To ensure in safety and quality, it meets IEC standard and TIS Standard for grounding and bonding equipments.
Material
High tensile strength steel
Copper purity > 99.9%
Tested Standard
IEC 62561 Part 2
TIS 3024 Part 2
Certified Mark
TIS
Application
Suitable for disperse current into the earth.
| Code No. | Nominal Diameter | Actual Diameter | Threaded Size | Length (m) | Weight |
| Dia. (inch) | Dia. (mm) | (kg) | |||
| GRCBT 124 TIS | 1/2″ | 12.7 | 1/2″ | 1.20 | 1.23 |
| GRCBT 126 TIS | 1/2″ | 12.7 | 1/2″ | 1.80 | 1.85 |
| GRCBT 128 TIS | 1/2″ | 12.7 | 1/2″ | 2.40 | 2.47 |
| GRCBT 1210 TIS | 1/2″ | 12.7 | 1/2″ | 3.00 | 3.08 |
| GRCBT 584 TIS | 5/8″ | 14.2 | 5/8″ | 1.20 | 1.54 |
| GRCBT 586 TIS | 5/8″ | 14.2 | 5/8″ | 1.80 | 2.31 |
| GRCBT 588 TIS | 5/8″ | 14.2 | 5/8″ | 2.40 | 3.08 |
| GRCBT 5810 TIS | 5/8″ | 14.2 | 5/8″ | 3.00 | 3.80 |
| GRCBT 344 TIS | 3/4″ | 17.2 | 3/4″ | 1.20 | 2.23 |
| GRCBT 346 TIS | 3/4″ | 17.2 | 3/4″ | 1.80 | 3.35 |
| GRCBT 348 TIS | 3/4″ | 17.2 | 3/4″ | 2.40 | 4.46 |
| GRCBT 3410 TIS | 3/4″ | 17.2 | 3/4″ | 3.00 | 5.58 |
