CCP-E – Manual Call Point, Conventional
Description:
The CCP-E is a Conventional call-point based upon the industry standard KAC world series housing and features easy to install, push-fit wiring terminals. The unit can support either a ‘Frangible Glass’ element or a ‘Non Frangible Plastic’ element.
IMPORTANT NOTE: If changing the element from Glass to Flexi, please confirm the operation by pressing the resettable element.
Standard Features:
Approved to EN54-11:2001
Terminals can accommodate up to a 2.5 mm2 solid conductor
Specification:
| Ordering codes | CCP-E – Red | |||
| Nominal operating resistance | 470 Ω | |||
| Maximum contact resistance (R) | 200 Ω | |||
| IP rating | IP24 | |||
| Operating / Storage temperature range | -10 °C to + 55 °C | |||
| Maximum Humidity | 95% RH – non-condensing (at 40°C) | |||
| Colour / Case Material | Red | |||
| Weight (g) / Diameter (mm) / Height (mm) | 110 / W 89 x H 93 x D 27.5 (Flush mount) 161 / W 89 x H 93 x D 59.5 (Flush mount) |
|||
| Accessories | Frangible element | KAC/G/HE | Non-frangible element | KAC/EWS/HE |
Resources and Downloads
| CCP-E – Manual Call Point | Download PDF |
| Hochiki_HCV-2-4-8_02-2010 | Download PDF |
| Hochiki_HCV Series Conventional Panel Manual V1.03 | Download PDF |
