LPI® Transient Earth Clamp
LPI’s new and improved transient earth clamp (TEC100-2L) prevents earth potential differences by operating only under transient conditions to effectively clamp all connected earths together. Under normal conditions, the TEC100-2L presents an effective open circuit. Once the earth potential difference exceeds the breakdown voltage of the TEC100-2L, conduction immediately occurs and the earth potentials are equalised. The TEC100-2L is a self-restoring device and has a life of over ten thousand operations.
Features
– 100 kA 10/350 μs or 200 kA 8/20 μs
– IP66
– Can be direct buried
– Equipotential bonding
– Easy installation
Product code: TEC100-2L
Application: Prevents earth potential differences
Rated DC sparkover voltage (1 kV/μs): 600 V
Impulse sparkover voltage (1 kV/μs): <1.5 kV
Max. Discharge current (Imax): * 200 kA 8/20 μs
Max. Discharge current (Iimp): * 100 kA 10/350 μs
Insulation resistance (at 100 Vdc): > 1 G Ohms
Max Continuous operating voltage (Vc): * 255 V rms
Volt current capability (If): * 100 A rms
Operating temperature: -40 ºC to +90 ºC
Environment rating: IP 66
Dimensions: 600 mm (L) x 40.0 mm Ø
Mounting: 2 x 300 mm flying lead (centre to centre) M10 crimp lug
Weight: 220 g
* As defined in IEC61643-11.
