Earth Points with pre-welded tail
LPI earth points are designed for use in reinforced concrete foundations and offer a convenient earth system connection point. Earth points supplied with tails allows for earthing to the building frame (foundations or rebar) in a safe and simple method.
The use of LPI earth points enables the installer to locate the complete earthing system within the structure and provides a location free from possible damage or unauthorised disconnection. LPI earth points are manufactured from a copper alloy and provide a current carrying capacity equal to that of the conductor or stud. Earth points will not corrode or loosen over time.
| Earth Points with pre-welded tail |
| Code |
No. Holes |
Thread |
Weight |
Rebar |
Description |
| EP1M1257T |
1 |
M12 |
810 g |
|
Earth Point 1 Hole with pre-welded 500 mm PVC Insulated 70 mm² Cable |
| EP1M1257TR |
1 |
M13 |
860 g |
Length 100 mm x Diameter 10 mm Rebar |
Earth Point 1 Hole with pre-welded 500 mm PVC Insulated 70 mm² Cable and Rebar |
| EP2M1257T |
2 |
M14 |
700 g |
|
Earth Point 2 Holes with pre-welded 500 mm PVC Insulated 70 mm² Cable |
| EP2M1257TR |
2 |
M15 |
750 g |
Length 100 mm x Diameter 10 mm Rebar |
Earth Point 2 Holes with pre-welded 500 mm PVC Insulated 70 mm² Cable and Rebar |
| EP4M1257T |
4 |
M16 |
950 g |
|
Earth Point 4 Holes with pre-welded 500 mm PVC Insulated 70 mm² Cable |
| EP4M1257TR |
4 |
M17 |
1000 g |
Length 100 mm x Diameter 10 mm Rebar |
Earth Point 4 Holes with pre-welded 500 mm PVC Insulated 70 mm² Cable and Rebar |
